KLF4 Antibody (C-term) western blot analysis in A431,MCF-7 cell line lysates (35ug/lane).This demonstrates the KLF4 antibody detected the KLF4 protein (arrow).

Fluorescent confocal image of SY5Y cells stained with BD-PB0983 KLF4 (C-term) antibody. SY5Y cells were fixed with 4% PFA (20 min), permeabilized with Triton X-100 (0.2%, 30 min), then incubated with BD-PB0983 KLF4 (C-term) primary antibody (1:200, 2 h at room temperature). For secondary antibody, Alexa Fluor? 488 conjugated donkey anti-rabbit antibody (green) was used (1:1000, 1h). Cytoplasmic actin was counterstained with Alexa Fluor? 555 (red) conjugated Phalloidin (5.25 μM, 25 min). KLF4 immunoreactivity is localized very specifically to the nuclei of the SY5Y cells.

KLF4 Antibody (C-term) flow cytometric analysis of K562 cells (right histogram) compared to a negative control cell (left histogram).FITC-conjugated goat-anti-rabbit secondary antibodies were used for the analysis.
